• Control

  • IR remote control
  • VISCA/pelco and P/pelco D via RS232
  • UVC/plug-and-play
  • PTZApp



• Optional Accessories

  • Mini DIN 6 to RS232 adapter for camera
  • Expansion Speakerphone (10 m cable included, daisy-chain up to three speakerphones)
  • Expansion Pair Microphone (Two 5 m cables included, daisy-chain up to four microphones)
  • USB 2.0 type-C to type-A Cable (16 ft)

• Warranty**

  • Camera/Speakerphone: 3+2 years
  • Accessories: 1 year



• Security and Mount

  • Camera mount included for wall or ceiling
  • Kensington slot

• System Requirements*

  • Windows® 7/10 or later
  • Mac OS X v10.13 or later
  • Google Chromebook™ version 76.0.3809.102 or later
  • Android™ 6 or later



• Hardware Specifications*

  • Processor: 3.2 GHz Intel® Core™i5-4460 or later
  • 4 GB RAM
  • USB 3.1 port, backward compatible with USB 2.0 port

• Free Applications for Meeting Collaboration (for Windows® and Mac Devices)

  PTZApp

  • Upgrade firmware automatically or manually
  • Control camera
  • Set parameters and adjust camera image
  • Diagnose operating status
  • View live video

  EZLive

  • Real-time streaming / annotating / snapshots /video recording



• Environmental Data

  • Operation temperature: 0°C ~ 40°C
  • Operation humidity: 20% ~ 80%
  • Storage temperature: -20°C ~ 60°C
  • Storage humidity: 20% ~ 80%

• Dimensions

  • Package dimensions: 259 x 259 x 349 mm
  • Package weight: 4.6 kg
  • Camera: 130.7 x 97.8 x 171.1 mm
  • Speakerphone: 220 x 181.5 x 49.5 mm
  • Remote control: 200 x 50 x 21 mm



• Package Contents

  • CAM540 Camera
  • FONE540 Speakerphone
  • Remote control
  • Power adapter x 2
  • Power cord (6 ft)
  • USB 3.1 type-C to type-A Cable (6 ft)
  • Micro USB 2.0 to Type-A cable (16 ft)
  • 3.5 mm aux cable (3 ft)
  • Warranty card
  • Quick Start Guide
  • Metal mount, tripod screws
  • Batteries

• Compatible Applications

  • Zoom, Microsoft® Teams, Skype for Business, Skype, Google Meet, Intel® Unite™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting ®, TrueConf, Adobe® Connect™, Cisco Webex®, Fuze, GoToMeeting™, Vidyo, vMix, WebRTC, Wirecast, XSplit



* For 4K UHD support, please check your system/hardware requirements with your software application provider.
** Please register online to receive a free 2-year warranty extension. For detailed warranty information, please contact an AVer representative.
*** Specifications may vary depending on location and are subject to change without notice.
