SPECIFICATION

Woofer: 10"

Type: 2-way 3-unit system

Crossover Frequency: 1.2 KHz

Frequency Responses: 50Hz-20KHz

Nominal Impedance: 8Ω

Power Handling (AES): 120W

Program Power: 240W

Sensitivity: 91dB

Net Weight: 11.1kg

Dimensions (mm): 294 (H) x 512 (W) x 279.5 (D)

CAUTIONS

Do not install the appliance on or at unstable location since it is rather heavy. If the loudspeaker is not identified as magnetically shielded, please do not place it near the TV set in order  to avoid magnetizing the TV screen. Do not place the loudspeaker in a location where it will be exposed to direct sunlight, high temperature or  high humidity. Be sure to turn off your amplifier before connection or disconnecting speakers. Do not operate the speaker with power exceeding limitation, as it may damage the speaker. Do not turn up the volume too much when a graphic equalizer is used to turn up for a higher sound level. Do not turn up for a higher sound level with a lower power amplifier, or it may damage tweeter speakers. Keep the volume control of your amplifier at the low position when first turn it on to avoid damaging. Use a clean dry cloth to wipe off dirt. Do not use volatile solvents such as alcohol, paint thinner, gasoline or benzene, etc to clean the cabinet.
