Brightness*2:
White Light Output (Normal/Eco):3,300lm / 2,050lm
Colour Light Output:3,300lm
Contrast Ratio:
Contrast Ratio:15,000:1
Internal Speaker(s):
Sound Output:2W Mono
Connectivity:
USB Interface:USB Type A: 1 (for USB Memory, USB Document Camera, for Wireless LAN Unit, Firmware Update)
USB Type B: 1 (for USB Display, Mouse, K/B, Control, Firmware Update)
Analog Input:D-Sub 15pin: 1 (Blue molding)
Composite: RCA x 1 (Yellow)
Digital Input:HDMI: 1 (MHL not supported)
Audio Input:2 RCA (White / Red): 1
Network:
Wireless:Yes (Optional)
Operating Altitude:
Operating Altitude:0 - 3,000 m <0 - 9,843 ft> (over 1,500m / 4,921ft: with high altitude mode)
Start-Up Period:
Start-Up Period:About 6 seconds, Warm-up Period: 30 seconds
Cool Down Period:
Cool Down Period:Instant Off
Air Filter:
Maintenance Cycle*4:6,000 hours / 10,000 hours
Dimension Excluding Feet (W x H x D):
Dimension Excluding Feet (W x H x D):302 x 77 x 234 mm
Geometric Correction:
Vertical/Horizontal Keystone:±30° / ±30°Auto Keystone:Yes (Vertical only)Horizontal Slide Keystone Correction:Yes
Direct Power On/Off:
Direct Power On/Off:Yes
Start Up Period:
Start Up Period:About 6 seconds, Warm-up Period: 30 seconds
Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system
Fan Noise:
Fan Noise (Normal / Eco):37dB / 28dB
Specifications of Main Parts:
LCD:Size: 0.55” (D10)
Native Resolution: XGA
Lamp:Type: 210W UHE
Life (Normal / Eco)
*1: 6,000 hours / 10,000 hours
Wireless Specifications (Wireless LAN):
Supported Speed For Each Mode*3:IEEE 802.11b (2.4GHz): 11 Mbps
IEEE 802.11g (2.4GHz): 54 Mbps
IEEE 802.11n (2.4GHz): 130 Mbps
Wireless LAN Security:Quick Mode: WPA2-PSK, Advanced Mode: WPA/WPA2-PSK
Supported Connection Mode:Infrastructure, Access Point
Weight:
Weight:Approx 2.5kg
Projectors Facets:
Resolution, Projectors Facets:XGAContrast Ratio, Projectors Facets:15,000:1Brightness Range Lumens, Projectors Facets:2000Laser / Lamp, Projectors Facets:LampFeatures, Projectors Facets:Wifi
