The Versatile Home Entertainment Projector.

The CO-FH01 is Epson's versatile lifestyle projector for both work and play. Featuring a Full HD resolution and 3,000 lumens of brightness, this all-in-one projector allows you to project a big screen experience in the home and office, at an affordable price. Even in bright rooms, this powerful yet affordable Full HD projector delivers high quality images anywhere, anytime. This is all thanks to Epson's 3LCD technology, which produces an equally high white and colour light output of 3,000 lumens1. Supersize and immerse yourself in your favourite movies and games with this Full HD projector, that's capable of creating an impressive 391-inch display.

=       Full HD resolution

=       Stunning Picture Quality up to 391"

=       3000 lumens of Colour and White brightness

=       5W Speaker

Specifications:

Projection Technology:

Projection Technology: RGB liquid crystal shutter projection system (3LCD)

Specifications of Main Parts:

LCD:

Size: 0.62-inch (C2 Fine)

Native Resolution: FHD

Lightsource:

Life (Normal / Eco): 6,000 / 12,000 hours (Normal / Eco)

Type: Lamp (Fixed), 188 W UHE

Projection Lens:

Type: No optical zoom / Focus (Manual)

F-Number: 1.44

Focal Length: 16.4mm

Zoom Ratio: 1.0 – 1.35 (Digital Zoom)

Throw Ratio: 1.19 – 1.61

Connectivity:

USB Interface:

USB Type A: 1 (For Wireless LAN, Firmware Update, Copy OSD Settings)

USB Type B: 1 (For Firmware Update, Copy OSD Settings)

Network:

Wired LAN: N/A

Wireless: Optional (ELPAP11)

Analog Input:

D-Sub 15pin: N/A

Composite: N/A

Audio Input:

N/A

Audio Output:

N/A

Video Input:

HDMI: 1

Screen Size (Projected Distance):

Screen Size (Projected Distance):

34” to 391” [0.89 to 10.40m] (Zoom: Wide)

26” to 290” [0.91 to 10.41m] (Zoom: Tele)

Standard size: 60” screen 1.58m

Geometric Correction:

Vertical/Horizontal Keystone:

Vertical: ± 30 degrees

Horizontal: ± 30 degrees

Auto Keystone:

N/A

Quick Corner:

Yes

Image Enhancement:

Scene Adaptive Gamma:

Yes

Aspect Mode:

Yes

Start-Up Period:

Start-Up Period:

About 6 seconds / Warm-up period: 30 seconds

Operating Temperature:

Operating Temperature:

5 - 40 °C <41 - 104 °F> (0m / 0ft - 2,286m / 7,500ft)

5 - 35 °C <41 - 95 °F> (over 2,286m / 7,500ft)

[20%-80% Humidity, No Condensation]

Operating Altitude:

Operating Altitude:

0 m to 3,048 m <0 ft to 10,000 ft>

Power:

Power Consumption:

Normal / Eco: 270W / 214W

Standby (Network On / Off): N/A / 0.5W

Power Supply Voltage:

100 - 240 V AC ±10%, 50/60 Hz

Internal Speaker(s):

Sound Output: 5W Monaural

Weight:

Weight: Approx. 2.4 Kg

Direct Power On/Off:

Direct Power On/Off: Yes

Dimension Excluding Feet:

Dimension Excluding Feet (D x W x H): 211 x 295 x 82 mm

Wireless Specifications (Smart Media Player Function):

Wireless LAN Generation:

Wi-Fi 5

Frequency Used:

IEEE 802.11a (5GHz),

IEEE 802.11b (2.4GHz),

IEEE 802.11g (2.4GHz),

IEEE 802.11n (2.4GHz and 5GHz),

IEEE 802.11ac (5GHz),

Supported Codec:

WPA2/WPA3-PSK (AES)

Colour Mode:

Colour Mode:

Dynamic, Vivid, Cinema, Presentation, Blackboard, sRGB

Brightness:

White Light Output (Normal/Eco): 3,000 lm / 2,000 lm

Colour Light Output: 3,000 lm

Light Output (Center): Yes [High, Low (Eco)]

Wireless Specifications (Optional Wireless LAN):

Supported Speed for Each Mode:

IEEE 802.11b (2.4GHz): 11 Mbps*3, IEEE 802.11g (2.4GHz): 54 Mbps*3, IEEE 802.11n (2.4GHz)*3: 72.2 Mbps*3, IEEE 802.11a (5GHz*3: 54 Mbps*3, IEEE 802.11n (5GHz)*3: 150 Mbps*3

Supported Mode:

Infrastructure, Access Point

Supported Security Type:

Infrastructure: Open, WPA2/WPA3-PSK

Access Point: WPA2-PSK (AES)

Cool Down Period:

Cool Down Period:

Instant Off

Fan Noise:

Fan Noise (Normal / Eco): 38dB / 29dB
