Projecting every detailed moment

Level up your home entertainment experience with EH-TW7000. With equal colour and white brightness of 3,000 lumens and 4K PRO-UHD4 technology, enjoying crisp and clear images is now made possible, right in the comfort of your home.



Specifications:

Projection Technology:

Projection Technology:

RGB liquid crystal shutter projection system

Specifications of Main Parts:

LCD:

Size: 0.61” wide panel (D10, C2 Fine, 10Bit)

Native Resolution: 1080p

Projection Lens:

Type: Optical Zoom (Manual) / Focus (Manual)

F-Number: 1.49 - 1.77

Focal Length: 18.2 - 29.2 mm

Zoom Ratio: 1 - 1.62

Lamp:

Type: 200W UHE

Life (High / Medium / Eco): 3,500 / 4,000 / 5,000 hours

Screen Size (projected distance):

Standard size: 100" screen [2.95 to 4.77 m]

Wide: 40" to 500" [1.16 to 14.87 m]

Tele: 40" to 500" [1.89 to 24.01 m]

Brightness:

White Light Output (Normal/Eco):

3,000 lm / 2,000 lm

Colour Light Output:

3,000 lm

Connectivity:

USB Interface:

USB Type A: 2 (Port 1: Wireless LAN, Firmware Update, Copy OSD Settings / Port 2: For Streaming Media Player with 2,000 mA Power Supply)

USB Type Mini-B: 1

Network:

Wired LAN: N/A

Wireless: Optional (ELPAP10)

Digital Input:

DVI-D: N/A

HDMI Type A: 2 (HDCP 2.2)

SDI: N/A

HDBaseT: N/A

Output Terminal:

D-Sub 15Pin: N/A

Audio Input:

Stereo Mini Jack: N/A

Audio Output:

Stereo Mini Jack: 1

Control I/O:

RS-232C: N/A

Remote Control Input: N/A

Contrast Ratio:

Contrast Ratio:

40,000:1

Geometric Correction:

Vertical Keystone:

±30 degrees

Adjustment Functions:

Picture In Picture:

N/A

Aspect Mode:

Yes

Frame Interpolation:

Off / Low / Normal / High (2D and 3D Mode)

Image Enhancement:

Image Preset Mode:

Yes

Mpeg Noise Reduction:

Yes

Super Resolution:

Yes

4K Enhancement:

Yes (On/Off)

Detail Enhancement:

Yes

Start-Up Period:

Start-Up Period:

Up to 19 seconds

Warm-up period: 30 seconds

Operating Temperature:

Operating Temperature:

5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft)

5 - 30 °C <41 - 86 °F> (Over 2,286 m / 7,500 ft)

(20% - 80% humidity, No condensation)

Operating Altitude:

Operating Altitude:

0 m to 3,048 m <0 ft to 10,000 ft>

Dimension Excluding Feet (W x H x D):

Dimension Excluding Feet (W x H x D):

410 x 157 x 310 mm

Weight:

Weight:

Approx. 4.1kg

Direct Power On/Off:

Direct Power On/Off:

Yes / N/A

3D Features:

3D Display:

Yes

3D Format:

Side by Side / Top and Bottom

3D Depth:

-10 to +10

2D - 3D Conversion:

N/A

Optional Wireless & Built In Lan Specifications:

Supported Speed for each Mode:

IEEE 802.11g (2.4GHz): 11 Mbps

IEEE 802.11b (2.4GHz): 54 Mbps

IEEE 802.11n (2.4GHz): 130 Mbps

Wireless LAN Security:

Quick Mode: WPA2-PSK

Advanced Mode: WPA/WPA2-PSK

Supported Connection Mode:

Infrastructure, Access Point

Cool Down Period:

Cool Down Period:

Up to 7 seconds

Fan Noise:

Fan Noise (Normal / Eco):

35dB / 24dB

Projectors Facets:

Resolution, Projectors Facets:

4K PRO-UHD

Contrast Ratio, Projectors Facets:

40,000:1

Brightness Range Lumens, Projectors Facets:

2000

4K PRO-UHD, Projectors Facets:

Yes

Features, Projectors Facets:

Quick Corner

Laser / Lamp, Projectors Facets:

Lamp

Screen Size, Projectors Facets:

40 - 500

Projector Primary Usage, Projectors Facets:

Living Room

Home Entertainment

Home Theater

Power Supply Voltage:

Power Supply Voltage:

100 - 240 V AC +/- 10%, 50/60 Hz

Power Consumption (220 - 240V):

Lamp On (Normal/Eco):

368W / 280W

Stand By (Network On / Off):

2.0W (Optional Wireless LAN) / 0.5W
