The Epic Entertainment Experience.

Whether you're watching live sports, gaming on the latest generation of consoles, or streaming your favorite movie, the Epson EpiqVision Ultra EH-LS800B delivers an epic big screen experience that will simply amaze you. With 4K PRO-UHD1 resolution, up to 150" screen size, Android TV function, and sound by YAMAHA, the EH-LS800B opens up a world of possibilities to create the ultimate home cinematic setting. Able to project 100" screen size at just 9.8cm away from the wall to the back of the projector, the EH-LS800B is currently the world's shortest ultra-short throw home projector.

=       Stunning 4K PRO-UHD1 picture

=       Immersive display

=       New Ultra-Short Throw Laser-Array Technology

=       Powered by Android TV

=       Best-in-Class Colour Brightness

=       4,000 lumens of colour and white brightness

=       HDR10 Support



Projection Technology:

Projection Technology:

RGB liquid crystal shutter projection system

Specifications of Main Parts:

LCD:

Size: 0.62” (C2 Fine)

Lightsource:

Type: Laser Diode

Life: 20,000 hours (Normal / Eco)

Aspect Ratio:

16:9

Projection Lens:

Type: No Optical Zoom / Focus (Manual)

F-Number: 1.8

Focal Length: 2.3 mm

Zoom Ratio: 1 – 2.5 (Digital Zoom)

Throw Ratio (Wide – Tele): 0.16 – 0.40

Resolution:

On-Screen (Maximum): 4K*1

Pixel Number: 4.2M Dots (1920 x 1080 x 2)

Native Resolution:

1080p

Brightness:

White Light Output (Normal/Eco):

4,000 lm / 2,000 lm

Colour Light Output:

4,000 lm

Connectivity:

Network:

Wireless: Yes (Only for Smart Media Player)

Digital Input:

HDMI: 3 (HDCP2.3)

Audio Output:

1 (Stereo Mini), 1 (S/PDIF)

Others:

USB Type A: 3 (for USB Storage, RJ45, Camera, Mic, HID) USB3 is for 5V/2A Power Supply, No USB Function

USB Type Mini-B: 1 (for Firmware Update)

Contrast Ratio:

Contrast Ratio:

Over 2,500,000:1

Screen Size (Projected Distance):

Standard Size:

90” screen 0.32 m

Zoom : Wide:

80” to 150” [0.28 to 0.54 m]

Zoom : Tele:

32” to 64” [0.28 to 0.54 m]

Image Enhancement:

Image Preset Mode:

Yes

Super Resolution:

Yes

Detail Enhancement:

N/A

4K Enhancement:

Yes (On/Off)

Aspect Mode:

Yes (Auto / Full / Zoom)

Frame Interpolation:

Yes (Off / Low / Normal / High)

Noise Reduction:

Yes (Except 4K Signal)

Start-Up Period:

Start-Up Period:

Less than 8 seconds, Warm-up period: 30 seconds

Operating Temperature:

Operating Temperature:

0 - 40 °C <32 - 104 °F> (0m / 0ft - 2,286m / 7,500ft)

0 - 35 °C <32 - 95 °F> (Over 2,286m / 7,500ft)

(20% - 80% Humidity, No Condensation)

Operating Altitude:

Operating Altitude:

0 m to 3,048 m <0 ft to 10,000 ft>

Over 1,500m / 4,921 ft, with High Altitude mode

Power:

Power Consumption:

LD On (Normal / Quiet, Extended): 335W / 210W

Standby (Network On / Off): 2.0W / 0.4 W

Power Supply Voltage:

100 - 240 V AC ±10%, 50/60 Hz

Internal Speaker(s):

Sound Output:

20W (YAMAHA 2.1ch Satellite x2, Woofer x1)

Weight:

Weight:

Approx. 12.3kg

Air Filter:

Maintenance Cycle:

20,000 H

Dimension Excluding Feet (W x H x D):

Dimension Excluding Feet (W x H x D):

341 x 695 x 145 mm

Wireless Specifications (Smart Media Player Function):

Wireless LAN:

Wi-Fi 5

Supported Speed For Each Mode:

IEEE 802.11a (5GHz) , IEEE 802.11b (2.4GHz), IEEE 802.11g (2.4GHz), IEEE 802.11n (2.4GHz and 5GHz)3, IEEE 802.11ac (5GHz)

Bluetooth:

Bluetooth 5.0 Class 2 (2.4GHz)

Supported OS:

Android OS

Supported VOD Platform:

Android TV

Video Output Resolution:

Up to 3,840 x 2,160 60fps at 4:2:0

Streaming Media Player:

Supported Operating System:

Android 11

Audio:

L-PCM, AC-3, DTS

Cool Down Period:

Cool Down Period:

Instant Off

Fan Noise:

Fan Noise (Normal / Eco):

32dB / 19dB
