Hisense HAIO136 136” LED All-in-one Display

MYR146354.00

Brand: Hisense

  • Share

Get shipping estimates

Country
State
Shipping Method

HAIO136

136” LED All-in-one Display

Create the ultimate immersive AV experience for your boardroom with the Hisense All-In-One LED display. Delivering vivid detail and unrivalled color depth, the All-In-One 136” LED display will provide finishing touch to any quality meeting space.





Specifications

Physical Parameter

Pixel Pitch: 1.5625 mm

Pixel Configuration: 3 in one SMD

Screen Resolution (W x H): 1920x1080

Module Dimensions (W x H): 150 x 337.5mm / 5.9 x 13.3inch

No. of Modules Per Screen (W × H): 20 x 5 (Total 100 Pcs LED Modules)

Screen Dimensions (W x H x D): 3004 x 1774.5 x 32.3mm / 118.3 x 69.9 x 1.27inch (with Screen Frame)

Cabinet Dimensions (W × H × D): 600 x 337.5 x 29.3mm / 23.6 x 13.3 x 1.15inch

Weight (per Cabinet/per Screen): 4kg / 110Kg [8.82lbs / 242.55lbs]

Pixel Density: 409,600 pixels/m2

Flatness Of Cabinet: ± 0.05 mm

Cabinet Material: Die-cast Aluminum

Gray Level: 14 bits

Aspect Rati: 16:9

Service Access: Front

Optical Parameter

Brightness: 100~600 Nits Adjustable

Contrast Ratio: 5,000 : 1

Visual Viewing Angle (H x V): 150° x 140°

Brightness Uniformity: 95%

Color Uniformity: ± 0.003 Cx,Cy

Processing Depth: 16 bits

Color Temperature - Default (Adjustable): 9300 K (2,000 ~ 9,300 K)

Electrical Parameter

Power Supply Voltage: 100 - 240 V, 50/60Hz

Average Power Consumption (W/ Screen): ≤ 800W

Max Power Consumption (W/ Screen): ≤ 1800W

Refresh Rate: 3,840 Hz

Operation Conditions

Operating Temp/Humidity: 0 - 40 °C/ 10% - 90%RH (no  frost)

Storage Temp/Humidity: -20 - 40 °C/ 10% - 65%RH (no  frost)

IP Rating: IP50

Expected LED Lifetime (typ): 100,000 Hrs

Speaker

Built-in: 10W×6

External: 3.5-mm AUDIO external sound system connector (prior to the built-in sound system connector)

System

OS: Android 9.0

CPU: CA73*4 1.3GHz

GPU: G52 MC1

DDR: 3GB

ROM: 64GB

Language: Chinese/English(Default)/ French, German, Spanish, Italian, Polish, Arabic

Features: HDR/EMMC/Low blue light/Dolby/DTS

Certification

Standard Certification: CE, CB, FCC, RCM, cTUVus

Environment: RoHS, REACH

Controller

Embedded

Available Regions

EU

USA

APAC

SA
