Physical Parameter

Pixel Pitch: 1.875 mm

Pixel Configuration: 3 in one SMD

Screen Resolution: 1,920 x 1,080

Module Dimensions (W x H): 150 x 337.5mm / 5.9 x 13.29inch

Screen Dimensions (W x H x D): 3605 x 2027 x 40mm / 141.93 x 79.8 x 1.57inch (w/o Screen Frame)

Physical Resolution of Module:  80 x 180

Physical Resolution of Panel: 320 x 180

LED Module Dimensions (mm): 150 x 337.5mm

No. of Cabinet Per Screen:  6 x 6

No. of Modules Per Cabinet: 4 x 1

Panel Dimensions (mm): 600 x 337.5 x 40mm

Screen Weight: ≤6.5kg / 230Kg [14.33lbs x 507.15lbs] (w/o Screen Frame)

Cabinet Material: Die-cast Aluminum

Gray Level (bit): 14 bits

Aspect Ratio: 16:9

Optical Parameter

Brightness (adjustable): 500 nits

Contrast Ratio: 3,000 : 1

Visual Viewing Angle (H x V): 160° x 160°

Brightness Uniformity: 95%

Color Uniformity: ± 0.003 Cx,Cy

Processing Depth: 16 bits

Color Temperature - Default (Adjustable): 6500 ± 200 K (2,000 ~ 9,300 K)

Electrical Parameter

Power Supply Voltage: 100 - 240 V

Average Power Consumption (W/ Screen): ≤ 1200

Max Power Consumption (W / Screen): ≤ 2800

Refresh Rate: 3,840 Hz

Operation Conditions

Operating Temp/Humidity: -20 - 40 °C/ 10% - 90%RH (no frost)

Storage Temp/Humidity: -20 - 40 °C/ 10% - 65%RH (no frost)

IP Rating: IP50

Expected LED Lifetime (Max): 100,000 Hrs

Speaker

Built-in: 30W x 2

External: 3.5-mm AUDIO external sound system connector (prior to the built-in sound system connector)

System

OS: Android 9.0

CPU: CA73 x 4 1.3GHz

GPU: G52 MC1

DDR: 3GB

ROM: 64GB

Language: English

Curve Installation

Curve Support (-:concave +: convex): Flat

Certification

CE / CB / FCC / ETL

Controller

Built-in

Available Regions

EU

USA

APAC

SA
